Application:
1. Analyzing the inspection
2. Education and scientific research
3. Exclusive photography
4. Particular conveyance
| Item |
Data |
Item |
Data |
| Size |
1043*798*440mm |
Platform size |
844*430mm |
| weight |
90kg |
load capacity |
100kg |
| Body Material |
Alloy plate//Aluminum |
Surface Treatment |
Powder Coat |
| Ground Clearance |
150mm |
Protection Grade |
IP64 |
| Steering Mode |
Differential steering |
Tread |
631mm |
| Ditch Passing Ability |
400mm |
Over-obstacle Capacity |
140mm |
| Tire Diameter |
440mm |
Wheel base |
607mm |
| Running speed |
10km/h |
Climbing angle |
30° |
| Motor |
48 DC brushless motor |
Reducer |
Precision/Grinding planetary reducer |
| Rated Torque |
70N.M |
Transmission Ratio |
24:10 |
