| Item | Data | Item | Data |
| Body Material | Alloy steel plate/Aluminum alloy | Size | 908*708*310mm |
| Tire Diameter | 310mm | Platform Dimension | 786*426mm |
| Self Weight | 60kg | Max. Load | 50kg |
| Motor | 48V DC Brushless Motor | Terrain Clearance | 98mm |
| Protection Grade | IP64 | Wheel Base | 595mm |
| Steering Mode | Differential steering | Rated Torque | 40NM |
| Ditch Passing Ability | 250mm | Over-obstacle capacity | 150mm |
| transmission ratio | 10 | Climbing Ability | 30° |
| Surface Treatment | Yellow coating | Running Speed | 16KM/H |
